PREMIUM TILE ADHESIVES, GROUTS & TILE CLEANER New Avatar New Approach New Face

ADHESIVES ADHESIVES ADHESIVES ADHESIVES ADHESIVES ADHESIVES GROUTS GROUTS GROUTS GROUTS GROUT ADMIX TILE CLEANER SEGMENT PRODUCT PAGE No. PREMIUM TILE ADHESIVES - CX-1 PREMIUM TILE ADHESIVES - VX-1 PREMIUM TILE ADHESIVES - CX-2 (WHITE) PREMIUM TILE ADHESIVES - VX-2 (WHITE) PREMIUM TILE ADHESIVES - EX-5 PREMIUM TILE ADHESIVES - EA-100 PREMIUM EPOXY GROUT - KE-100 PREMIUM EPOXY GROUT - KE-100 DUET PREMIUM EPOXY GROUT - KE-100 GLITTER PREMIUM UNSANDED GROUT PREMIUM GROUT ADMIX - KGA-01 TILE CLEANER- TC1 10 12 14 16 18 20 24 26 28 30 32 33 INDEX

The largest manufacturer of ceramic and vitrified tiles in India. Equipped with cutting-edge technology, we at Kajaria strive to deliver quality products and services to our customers. Our team of experts work around the clock to ensure that the quality of our product is never compromised. When tiles are fixed to any surface, most vulnerable point is always the bond between the tile and substrate. We eliminate this weakness by significantly improving the bonding strength of the adhesive to both the tile and substrate. PRESENT INNOVATIVE TILE SOLUTIONS WITH THE BEST PERFORMANCE GRESBOND by Kajaria offers you wide range of tile adhesives & grouts for fixing of various categories of tile for faster laying & long lasting applications. • PREMIUM ADHESIVES • PREMIUM EPOXY GROUT • PREMIUM UNSANDED GROUT • PREMIUM GROUT ADMIX • PREMIUM TILE CLEANER Our GRESBOND Basket is consist of :

INGREDIENTS FOR PERFECT RESULTS PREMIUM ADHESIVES, GROUTS & TILE CLEANER Type 2 Type 1 Type 2

The tile adhesive is applied in a thin layer by means of a notched trowel. The tiles are placed with spacers and adjusted accordingly. To complete the installation, joints are filled with premium Epoxy grout.

PERFECT SOLUTION FOR TILE FIXING EASY LAYING OF TRENDING LARGE TILES/ STONES Cement-based tile adhesives adhere very well to porous substrates such as bricks, plasters, earthenware tiles and stoneware tiles. These structures are good anchors for the calcium silicate hydrate needles that form when cement hardens. In contrast, modern porcelain stoneware tiles have extremely smooth surfaces. Tile adhesives for the tiles must be highly modified to attain the necessary tensile adhesion strength coupled with high flexibility. Tiles require high-quality grouts. Good adhesion at the tile edges, good abrasion resistance and limited water uptake coupled with good water-vapour permeability. High quality grouts play important role in the laying of the tiles: like flexible tile adhesives, thy compensate for any stresses that may arise. The trend toward large-format tiles is continuing. These tiles create a spacious and luxurious environment. At the same time, they are easier to clean. However, technical challenges also increase as the tiles get larger. Successful laying of large tiles depends on a variety of factors- improving the adhesion and increasing the flexibility of the adhesives with polymer powders plays a key role. 07

Type 3 TYPE-2/WHITE COLOUR GRESBOND PREMIUM TILE ADHESIVES 08 Type 2 Type 1 Type 2

Fast and Economical GRERBOND Premium Tile adhesive can be easily applied over large areas with a notched trowel. Then the tiles can be adjusted gently after laying to produce a uniform adhesive bed. Easy to work with GRESBOND High-quality tile adhesives for wall application have good non- slump properties. The freshly laid tiles therefore do not slip on the wall. It is thus possible to lay the tiles from top to bottom without using spacers. This makes it easier to produce a uniform pattern. Excellent Results GRESBOND advanced premium adhesives are so easy to mix and install that good results are consistently achieved. Irrespective of the tile material or the substrate, the tile adhesive can be custom-mixed for the particular tile type and substrate. Perfect Finish *not suitable for surfaces subject to vibration like plywood, metal, glass, gypsum boards, fibre cement slabs & smooth pre-fabricated concrete. High Bond Strength No Hollowness between Tile and Substrate Can be used directly on any surface* Resistant to Stains and Seepage Water Resistant Saves Time Surface ready to use within 24 hours White Adhesive specially for light base tile 09

CX-1 PREMIUM TILE ADHESIVE FOR CERAMIC FLOOR TILES Product Description: CX1 is grey cement based polymer modified quick set tile adhesive. It gives excellent bond on cementitious surfaces like concrete and plaster. CX1 Adhesive forms a waterproof barrier between two surfaces and has an excellent 'grab' properties. Pack Size: 20Kg. Color: Grey Shelf Life: 1 year in dry unopened bags. Coverage (in sq. mtr.)* 4-5 Sq. mtr. / 20 Kg bag at 3 mm thickness. Applications: For fixing all types of ceramic tiles on interior floor surfaces. Advantages: Ready to use. Needs only mixing with water. Flexible, shock and Impact resistant. Fast and economical. High bond strength. Suitable for ceramic floor tiles. *Coverage may vary according to evenness/level of floor Substrates: Concrete Floor Cement sand screed Cement Mortar Beds Plaster Brick Masonry 10

CX-1 Technical Data: (Type-1) Density Pot Life Open Time Adjustability Setting Time Full Strength Tensile Strength Shear Strength 1.79 kg/litre Approx. 1.5 hrs Approx. 22 minutes Approx. 21 minutes Approx. Approx. 1 Day Approx. 14 Days 2 >1.20 N/mm 2 >1.00 N/mm Method of Application: Press the tile gently with help of Wooden Hammer to make uniform tile surface. Use flat side of the trowel and spread the adhesive uniformly. Add 5 to 6* ltrs water in-to empty bucket. cx1 * The POWDER: LIQUID ratio may vary according to the job conditions 11

VX-1 Pack Size: 20Kg. Color: Grey Shelf Life: 1 year in dry unopened bags. Coverage (in sq. mtr.)* 4-5 Sq. mtr. / 20 Kg bag at 3 mm thickness. Applications: For vitrified & ceramic tiles and large format tiles on floor surfaces. Advantages: Ready to use. Needs only mixing with water. Also suitable for Marbles and tile on tile application. Can also we use for internal wall tile. Saves time as floors are ready to be used after 24 hours. Excellent adhesion & low shrinkage. Substrates: Concrete Wall & Floor, Cement sand screed, Cement Mortar Beds, Plaster, Brick Masonry Renovation works on existing: Unglazed Tiles Glazed Tiles, Mosaic Tiles* Vitrified & Ceramic Tiles *Coverage may vary according to evenness/level of Floor/Wall *Surface should be roughened and proper cleaned before fixing the tiles. HIGH PERFORMANCE PREMIUM TILE ADHESIVE FOR ALL KIND OF FLOOR & BATHROOM WALL TILES Product Description: VX1 is polymer modified grey cement based premium tile adhesive specially designed for heavy duty applicants for fixing vitrified tiles & large size tiles on floor surfaces. This highly flexible adhesive also has an excellent waterproofing ability. When properly applied, it takes care of hollowness problem. 12 Type 2

Method of Application: Press the tile gently with help of Wooden Hammer to make uniform tile surface. Use flat side of the trowel and spread the adhesive uniformly. Add 5 to 6* ltrs water in-to empty bucket. vx1 * The POWDER: LIQUID ratio may vary according to the job conditions Technical Data: (Type-2) Density Pot Life Open Time Adjustability Setting Time Full Strength Tensile Strength Shear Strength 1.7 kg/litre Approx. 3-4 hrs Approx. 23 minutes Approx. 22 minutes Approx. Approx. 1 Day Approx. 14 Days 2 >1.30 N/mm 2 >1.25 N/mm VX-1 13

CX-2 White Add more brightness to floors Pack Size: 20Kg. Color: White Shelf Life: 1 year in dry unopened bags. Coverage (in sq. mtr.)* 4-5 Sq. mtr. / 20 Kg bag at 3 mm thickness. Applications: For fixing all kind of ceramic floor tile. specially recommended for light base ceramic floor tile to give them more brightness & shine. Advantages: Ready to use. Needs only mixing with water. Flexible, shock and Impact resistant. Fast and economical. Highly effective for light base ceramic floor tiles. Protect light base ceramic tile from discoloration. Substrates: Concrete Floor Cement sand screed Cement Mortar Beds Plaster Brick Masonry WHITE COLOR PREMIUM TILE ADHESIVE FOR CERAMIC FLOOR TILES Product Description: CX2 White is white cement based polymer modified quick set tile adhesive. It gives excellent bond on cementitious surfaces like concrete and plaster. CX2 White Adhesive forms a waterproof barrier between two surfaces and has an excellent 'grab' properties. Highly recommended for light base Ceramic floor tiles. *Coverage may vary according to evenness/level of floor 14 Type 1

Technical Data: (Type-1) Density Pot Life Open Time Adjustability Setting Time Full Strength Tensile Strength Shear Strength 1.79 kg/litre Approx. 1.5 hrs Approx. 22 minutes Approx. 21 minutes Approx. Approx. 1 Day Approx. 14 Days 2 >1.20 N/mm 2 >1.00 N/mm Method of Application: Press the tile gently with help of Wooden Hammer to make uniform tile surface. Use flat side of the trowel and spread the adhesive uniformly. Add 5 to 6* ltrs water in-to empty bucket. cx2 * The POWDER: LIQUID ratio may vary according to the job conditions CX-2 White 15

VX-2 White Gives extra Whiteness to white marble/stones and tiles HIGH PERFORMANCE WHITE COLOR PREMIUM TILE ADHESIVE FOR FLOOR TILES, MARBLES & BATHROOM WALL TILES Product Description: VX2 White is polymer modified white cement based premium tile adhesive specially designed for heavy duty applicants for fixing vitrified tiles & large size tiles on floor surfaces. This highly flexible adhesive also has an excellent waterproofing ability. When properly applied, it takes care of hollowness problem. Highly recommended for light base internal wall & floor tile. *Coverage may vary according to evenness/level of Floor/Wall *Surface should be roughened and proper cleaned before fixing the tiles. Pack Size: 20Kg. Color: White Shelf Life: 1 year in dry unopened bags. Coverage (in sq. mtr.)* 4-5 Sq. mtr. / 20 Kg bag at 3 mm thickness. Applications: White color adhesive specially recommended for all kinds of floor Advantages: Ready to use. Needs only mixing with water. Also suitable for Marbles and tile on tile application. Can also we use for internal wall tile. Saves time as floors are ready to be used after 24 hours. Excellent adhesion & low shrinkage. Very effective for light base tiles & Marbles. Protect light base tiles from discoloration. Substrates: Concrete Wall & Floor, Cement sand screed, Cement Mortar Beds, Plaster, Brick Masonry Renovation works on existing: Unglazed Tiles Glazed Tiles, Mosaic Tiles* Vitrified & Ceramic Tiles 16 Type 2

Technical Data: (Type-2) VX-2 White Density Pot Life Open Time Adjustability Setting Time Full Strength Tensile Strength Shear Strength 1.7 kg/litre Approx. 3-4 hrs Approx. 23 minutes Approx. 22 minutes Approx. Approx. 1 Day Approx. 14 Days 2 >1.30 N/mm 2 >1.25 N/mm Method of Application: Press the tile gently with help of Wooden Hammer to make uniform tile surface. Use flat side of the trowel and spread the adhesive uniformly. Add 5 to 6* ltrs water in-to empty bucket. vx2 * The POWDER: LIQUID ratio may vary according to the job conditions 17

EX-5 HEAVY DUTY PREMIUM TILE ADHESIVE FOR INTERIOR & EXTERIOR WALL & FLOOR TILES Product Description: When performance matters, professionals choose technically advanced solution for excellent adhesion. EX-5 is a high strength polymer modified premium tile adhesive. EX-5 is specially designed for heavy duty tile application. It has superior strength and is ideal for wall cladding tiles, large format vitrified & ceramic tiles on internal & external floors. ** Fastening is recommended to install Slabs/ Big Size Tiles over Facade on High rise walls ***Coverage may vary according to evenness/level of Floor/Wall *Surface should be roughened and proper cleaned before fixing the tiles. Color: Grey Shelf Life: 1 year in dry unopened bags. Coverage (in sq. mtr.)* 4-5 Sq. mtr. / 20 Kg bag at 3 mm thickness. Applications: Suitable for exterior & interior surfaces in residential buildings for both floor & wall surfaces. Pack Size: 20Kg. Advantages: Suitable for all types of tiles for both interior & exterior solution. Excellent tensile & shear adhesion. Heat & weather resistant. Thermal Insulation. Substrates: Concrete Wall & Floor, Cement sand screed, Cement Mortar Beds, Plaster, Brick Masonry Renovation works on existing: Unglazed Tiles Glazed Tiles, Mosaic Tiles* Vitrified & Ceramic Tiles 18 Features Simply mix with water and it is ready to use. No curing required. Water resistant. High Strength Adhesive.

Technical Data: (Type-3) EX-5 Density Pot Life Open Time Adjustability Setting Time Full Strength Tensile Strength Shear Strength 1.7 kg/litre Approx. 3-4 hrs Approx. 25 minutes Approx. 23 minutes Approx. Approx. 1 Day Approx. 14 Days 2 >1.65 N/mm 2 >1.60 N/mm Method of Application: Press the tile gently with help of Wooden Hammer to make uniform tile surface. Use flat side of the trowel and spread the adhesive uniformly. Add 5 to 6* ltrs water in-to empty bucket. * The POWDER: LIQUID ratio may vary according to the job conditions **For exterior elevation tiles, add latex base adhesive mixture” 19

EA-100 HIGH STRENGTH EPOXY BASED ADHESIVE FOR TILES AND STONES Product Description: GRESBOND EA-100 is two component epoxybased adhesive specially designed for fixing all type tiles, Marble & Natural Stone on various substrates like Concrete, Cement mortar, Metal floor & wall, natural wood, plywood and vinyl tiles. Suitable for industries, commercial areas and residential areas. Features High Strength, Chemical resistant Bond with various substrates Stain free product Thermal shock resistant Fast bonding formula Highly Flexible | Easy to use Advantages: Suitable for large format tiles Ideal for moisture sensitive stone Ideal for spa, pools and water features Reliable bonding to vibrating substrates Heat resistant Substrates: Concrete Concrete masonry & Brick masonry Metal surfaces Wood & Plywood Cement Backer Board Epoxy or PU resin-based substrates Gypsum fibre board Stone & Marbles Shelf Life: 1 year in dry unopened bucket. Coverage (in sq. mtr.)* 4-5 Sq. mtr. / 10 Kg bucket at 3 mm thickness. Applications: Wall cladding on High rise building, Residences, Hotels, Kitchen, Balconies, Terraces, Commercial applications, Industrial applications Pack Size: 1 Kg, 5 Kg & 10 Kg New Launch 20

Add part 1 & part 2 in bucket and mix it till attains uniform paste 5 kg Consistency Colour Pot Life Loading Time Full Strength Tensile Adhesion Strength Shear Adhesion Strength Heat Ageing Condition Non Sag Paste Off White 45 minutes Approx 120 Minutes Approx 24 Hours >7.00-8.00N/mm 2 >8.00-9.00N/mm 2 7-9 / mm2 Technical Data: (Type-5) EA-100 Method of Application: Press the tile gently with help of Wooden Hammer to make uniform tile surface. Use flat side of the trowel and spread the adhesive uniformly. * Note: Company will not be responsible for any wrong application of the products. 21

Comparison between Traditional Cement Sand Mortar, Non branded Tile adhesive vs. GRESBOND Tile Adhesive *not suitable for surfaces subject to vibration like plywood, metal, glass, gypsum boards, fibre cement slabs & smooth pre-fabricated concrete. Type 3 Traditional cement Sand Mortar /non branded tile adhesive GRESBOND Premium Tile Adhesive Slow Fixing Curing Required Poor Workability Typical Application Short Open Time And Adjustability Poor Water Retention Very Low Bond Strength Hollowness Problem Required Bed Thickness 20-30 Mm Add More Weight and Thickness Not Water Resistant Chipping Required Stains, Seepage, & Discolouration Is Possible. Faster Fixing Curing Not Required Good Workability Easy to Apply Adequate Open Time and Adjustability Good Water Retention High Bond Strength No Hollowness Between Tile and Substrate 3-6mm Thickness Adequate Mostly Reduced Weight & Thickness of Structure Water Resistant Can be Use Directly on Any Surface Resistant to Stains, Seepage & Discolouration 22 Type 2 Type 2 Type 1

Type 2 ±2 C Property Min. requirement Typical Result 2 Tensile Strength (N/mm) Dry Condi on Wet Condi on 2 Shear adhesion strength (N/mm) Dry Condi on Wet Condi on Heat Aging Condi on Open me in minutes Adjustment me in minutes Slip (less than 0.5 mm) . 1.0 1.0 1.25 1.0 1.0 As per M r As per M r <0.50 . >1.30 >1.10 >1.30 >1.10 >1.25 23 22 <0.30 Type 3 ±2 C Property Min. requirement Typical Result 2 Tensile Strength (N/mm) Dry Condi on Wet Condi on 2 Shear adhesion strength (N/mm) Dry Condi on Wet Condi on Heat Aging Condi on Open me in minutes Adjustment me in minutes Slip (less than 0.5 mm) Deform ability . 1.50 N 1.00 N 1.50 N 1.00 N 1.00 N As per M r As per M r <0.50 ≥ 2.5, <5.0 mm . >1.65 N >1.10 N >1.60 N >1.10 N >1.00 N 25 23 0.35 mm 2.73 mm Property Min. requirement Typical Result 2 Tensile Strength (N/mm) Dry Condi on 2 Shear adhesion strength (N/mm) Dry Condi on Open me in minutes Adjustment me in minutes Slip (less than 0.5 mm) . 0.50 1.00 As per M r As per M r <0.50 . >1.20 >1.00 22 21 <0.30 Property Min. requirement Typical Result 2 Tensile Strength (N/mm) Dry Condi on 2 Shear adhesion strength (N/mm) Dry Condi on Heat Aging Condi on Slip (less than 0.5 mm) . Min 2.00 N Min. 6.00 N Min. 3.00 N ≤ 0.50 mm . 7.00- 8.00 N 8.00-9.00 N 6.00- 7.00 N 0.10-0.30 mm 23

KE-100 Advantages: Water Resistant Stain free grout for floors & walls. Available in range of colors. Chemical & Bacterial resistant. Enhances look of walls & floors. Easy to apply-Smooth & Creamy. Easy to clean. Uniform color resist blotching. PREMIUM EPOXY GROUT Product Description: GRESBOND KE-100 is a Stain free Epoxy grout for floors & Walls. It is a color fast, water & chemical resistant & 100 % solid epoxy grout suitable for Ceramic tiles, Vitrified tiles, marbles and stones, especially in stain prone areas such as kitchens and washrooms (residential & commercial installations). It is non shrinking, fast curing efflorescence free grout. It is ideal for installation where high strength mildew joints are required. It can be steam cleaned and is ideal for green buildings. Available in 1Kg and 5kg pack. Features Simply mix Hardener, resin & filler. Excellent under high temperature conditions. Beautiful Joints as no effect of pigments. Protection against Stains. Time Saving. Suitable for joints between 2-12 mm . Available in 20 colors. Applications: Residences, Kitchens, bathrooms, swimming pools, fountains, hospitals, restaurants, showroom, industrial areas & high traffic areas. Shelf Life: 1 year in dry unopened bucket. Pack Size: 1 Kg. 5 Kg. Resin Hardner Coated 0.2 Kg. 0.08 Kg. 0.720 Kg. 1 Kg. 0.4 Kg. 3.6 Kg. 24

KE-100 Grout Colours 25 Plain Elite Plain Aqua Crema Alpine Blue Champagne Rose Ivory Bottle Green Autumn Yellow Marble Beige Granilia Grey Steel Grey Almondo Cobalt Blue Fiero Chocolate Brown Black Copper Brown Turquoise Blue Blanco Nieve Coverage Chart* *Note: Coverage: Approximate Sq. Ft. coverage per # 1 unit (5 kg) of Gresbond. As per the actual site the consumption vary accordingly. These figures are for indicative purpose. * Know the material needed for your site Joint Width Tile Size X Thickness 2 mm 3mm 4 mm 6 mm 8 mm 10 mm 12 mm 264 296 269 263 394 405 506 591 515 590 177 198 181 175 263 270 337 394 343 393 133 143 136 132 198 202 253 295 258 295 90 100 91 88 132 135 169 197 171 197 68 75 69 66 100 101 127 148 129 148 55 61 55 53 80 81 101 119 103 118 46 51 46 44 67 68 85 99 86 99 100x100x3 150x150x4 200x150x5 150x300x6 300x300x6 450x300x7 600x450x8 600x600x8 600x900x11 900x900x12

KE-100 DUET Advantages: Shock Resistant Available in range of colours Enhances look of Walls & Floors Easy to apply & Easy to clean Water resistant Substrates: Ceramic Tiles Vitrified Tiles Glass Mosaic Tiles Granite & Marble Natural Stone & Marble PREMIUM EPOXY GROUT WITH TWO COMPONENTS Product Description: GRESBOND KE-100 DUET is high performance Epoxy based two components tile grout. Easy to use and suitable for all wall and floor tiles, marble and natural stone. It has high chemical & abrasion resistant. It also produces hygienic joints that needs minimal maintenance in Kitchen & Bathroom areas. Available in 20 colours. Suitable for joints between 2-12 mm. Available in 1 Kg & 5 Kg Pack. Features Hygienic & Chemical resistant Stain and bacterial resistant Provides high strength and durable joints Non-cracking formula Time Saving two components Suitable for submerged conditions Applications: Institutional and commercial kitchens, Cafeterias, Residences, Swimming Pools, Washrooms, Hospitals, Food Industries, Pharmaceutical Industries. Shelf Life: 1 year in dry unopened bucket. Pack Size: 1 Kg. 5 Kg. . Hardner 0.920 Kg. 0.08 Kg. 4.6 Kg. 0.4 Kg. Resin + Coated Filler 26 New Launch

KE-100 DUET Grout Colours Plain Elite Plain Aqua Crema Alpine Blue Champagne Rose Ivory Bottle Green Autumn Yellow Marble Beige Granilia Grey Steel Grey Almondo Cobalt Blue Fiero Chocolate Brown Black Copper Brown Turquoise Blue Blanco Nieve Coverage Chart* *Note: Coverage: Approximate Sq. Ft. coverage per # 1 unit (5 kg) of Gresbond. As per the actual site the consumption vary accordingly. These figures are for indicative purpose. * Know the material needed for your site Joint Width Tile Size X Thickness 2 mm 3mm 4 mm 6 mm 8 mm 10 mm 12 mm 264 296 269 263 394 405 506 591 515 590 177 198 181 175 263 270 337 394 343 393 133 143 136 132 198 202 253 295 258 295 90 100 91 88 132 135 169 197 171 197 68 75 69 66 100 101 127 148 129 148 55 61 55 53 80 81 101 119 103 118 46 51 46 44 67 68 85 99 86 99 100x100x3 150x150x4 200x150x5 150x300x6 300x300x6 450x300x7 600x450x8 600x600x8 600x900x11 900x900x12 27

KE-100 GLITTER EPOXY GROUT WITH SPARKLE EFFECTS Product Description: GRESBOND KE-100 GLITTER is specially designed to get special sparkle effects and enhance the beauty of tiles. It can be applied on both wall and floor, interior & exterior area. We can use it with ceramic tiles, vitrified tiles, natural stone & marble. Available in three sparkle effects (Gold, Silver, Copper). Suitable for joints between 2-12 mm. Available in 1 Kg & 5 Kg Pack. Features Provide Sparkling effects to tiles joints High Bond Strength and durable joints Suitable for Tiles, Marble & Granite Excellent chemical resistance Hygienic and stain free Applications: Restaurants, Hotels, Showrooms, Shopping Malls, Multiplexes, Washrooms, Kitchens, Marriage Halls Spa, Swimming Pool Shelf Life: 1 year in dry unopened bucket. Pack Size: 1 Kg. 5 Kg. Resin Hardner 0.2 Kg. 0.08 Kg. 0.720 Kg. 1 Kg. 0.4 Kg. 3.6 Kg. Sparkle Coated Filler Advantages: Colour fast & easy to clean Stain Free Gives Smooth & Aesthetic looks Easy to maintain Substrates: Ceramic Tiles Vitrified Tiles Glass Mosaic Tiles Granite & Marble 28 New Launch

KE-100 GLITTER Grout Effects (Gold, Silver & Copper) Gold Copper 29 Coverage Chart* *Note: Coverage: Approximate Sq. Ft. coverage per # 1 unit (5 kg) of Gresbond. As per the actual site the consumption vary accordingly. These figures are for indicative purpose. * Know the material needed for your site Joint Width Tile Size X Thickness 2 mm 3mm 4 mm 6 mm 8 mm 10 mm 12 mm 264 296 269 263 394 405 506 591 515 590 177 198 181 175 263 270 337 394 343 393 133 143 136 132 198 202 253 295 258 295 90 100 91 88 132 135 169 197 171 197 68 75 69 66 100 101 127 148 129 148 55 61 55 53 80 81 101 119 103 118 46 51 46 44 67 68 85 99 86 99 100x100x3 150x150x4 200x150x5 150x300x6 300x300x6 450x300x7 600x450x8 600x600x8 600x900x11 900x900x12

PREMIUM UNSANDED GROUT Advantages: Water resistant. Improved efflorescence control. Smooth finish. Weather resistant. Easy maintenance. Non-shrinking. Non-cracking. Easy application and clean up. Available in 20 colors. PREMIUM UNSANDED GROUT Product Description: GRESBOND Premium Unsanded Grout is a superior quality grout. It consist of a carefully prepared blend of cement, chemical additives and fillers. It is easy to install–just mix with water/grout admix and use. For best results, use with Premium Grout Admix KGA-01. It is ideal for both floors and walls applications. GRESBOND Premium grouts are suitable for a vast array of tile types and applications, including natural stone, porcelain, conglomerate and ceramic tiles. Pack Size: 1Kg. Shelf Life: 1 year in dry unopened bags. Applications: Used for filling tile joints with width 1mm to 3 mm in both interior and exterior areas for ceramic & vitrified tiles. For best results, use with GRESBOND Premium Grout Admix KGA-01. 30

Coverage Coverage ( in sq. ft.): Approximate. Sq. Ft. Coverage per 10 kg unsended grout. Tile Size x thickness (in mm) 1 mm 2 mm 3 mm 100 x 100 x 3 150 x 150 x 4 200 x 150 x 5 150 x 300 x 6 300 x 300 x 6 450 x 300 x 7 600 x 450 x 8 600 x 600 x 8 600 x 900 x 11 900 x 900 x 12 1430 1610 1470 1430 2150 2205 2755 3210 2804 3213 720 810 740 860 716 1104 1379 1610 1403 1608 480 540 490 478 710 737 920 1070 1070 1072 Grout Colours Plain Elite Plain Aqua Crema Alpine Blue Champagne Rose Ivory Bottle Green Autumn Yellow Marble Beige Granilia Grey Steel Grey Almondo Cobalt Blue Fiero Chocolate Brown Black Copper Brown Turquoise Blue Blanco Nieve 31

KGA-01 GROUT ADMIX PREMIUM GROUT ADMIX FOR USE WITH UNSANDED GROUT Product Description: GRESBOND Premium Grout Admix KGA-01 is a polymer based liquid admixture specially designed for use in combination with GRESBOND Grouts. It provides a dense, colorfast grout ideal for all interior and exterior applications. It improves the performance and does not allow any moisture/water to seep into the back of the tile. Pack Size: 400ml (Carton of 10 Bottles 4000 ml.) Shelf Life: 1 year Applications: For interior & exterior application Add 400ml of GRESBOND Premium Grout Admix KGA-01 in 1 kg grout and mix until a slump free & smooth grout is obtained. Advantages: For use in interiors and exteriors Provides smooth and uniform joints Shock & impact resistant No water leakage Features It locks the grout into the joint Seals, protects, and strengthens grout Same stain resistance as most grout sealers Grout and seal in one step Low VOC formula Features water repellant technology Shields grout from mold and mildew buildup Easy to clean Method of Application: Add 400ml of GRESBOND Premium Grout Admix KGA-01 in 1 kg grout and mix until a slump free & smooth grout is obtained. Apply mixture to the surface and work it well into the joints ensuring that they are completely filled. Remove excess grout while working diagonally over the area to be grouted. 32

Caution: Please note that this is an acidic based cleaner and hence care should be taken while using the same. Please wear hand gloves, nose cover and wear eye protection before and while using the product. KEEP OUT OF REACH OF CHILDREN TC1 TILE CLEANER Product Description: Features GRESBOND Tile Cleaner TC1 is a fast acting acid based cleaner for regular cleaning of dirt and stains on tile surface, designed for daily maintenance of tiles. New Improved formula. For all type of tile surface. Removes tough stains. Use directly or add water. Ideal for interior & exterior. Pack Size: 750ml (Carton of 14 Bottles 10500 ml.) Shelf Life: 1 year Applications: For interior & exterior application Dilute to the correct ratios as required. Use 1 part of cleaner to 4 parts clean water Heavily soiled areas may require an undiluted solution to be applied Always test initially on a small areas Liberally apply the solution to the floor area to be cleaned. Leave in contact with area for approx. 4-5 minutes Using a brush or a scrub pad thoroughly scrub the area treated with the solution. 33

Earn Points with Every Purchase Introducing the Mason Loyalty Program! & EARN POINTS coupon code TOKEN SAMPLE TOKEN SAMPLE
